Description
The KING of Long Range FPV! A super-efficient iFlight 7.5inch Long-Range bird that can go where you couldn’t go before and can carry bigger batteries to get the flight time to surf the swiss alps if you want! A super stiff frame for minimum resonance.
Specifications
Product Name：Chimera7 ECO Frame Kit
Wheelbase: 327mm
Frame Dimension: L270*W199*H34 mm
Frame Body Dimension: 34mm
Arm Thickness: 6mm
Bottom Plate Thickness: 3mm
Top Plate Thickness: 2mm
Upper Plate Thickness: 3mm
Camera Plate Thickness: 3mm
Max Flight Stack Height: 21mm
Max VTX Height: 30mm
Flight Stack Mounting: 30.5×30.5mm /φ3mm
VTX Mounting: 30.5*30.5 φ3mm / 25*25 φ1.6mm / 20*20 φ2mm
Motor Mounting: 16x16mm / 19*19mm φ3mm
Weight: 357g
NOTE: Due to manufacturing processes, the thickness of our products may have a standard manufacturing tolerance of ±0.2mm. The size of the hole may have a standard manufacturing tolerance of ±0.1mm.
Packing List
1 x Chimera7 ECO Frame Kit
1 x TPU Set
1 x Screw Bag
1 x Anti-Slip Battery Pad
2 x Battery Strap
4 x AMASS MR30 Plugs
Note：The vertical antenna mount will be in the box when shipped and needs to be installed by the customer.
