Specification:
Frequency:4.9GHz-5.2GHz
MAX Gain:2.68dBi(5050MHz)
MIN Gain:2.12dBi(5200MHz)
MAX VSWR:1.3606(5170MHz)
MIN VSWR:1.1728(5020MHz)
MAX radiation efficiency:88%(5080MHz)
MIN adiation efficiency:79%(5200MHz)
Polarization:RHCP
Cross polarization suppression:-25dB
Axial Ratio:≤ 3
Cable:RG141
Weight:11.5g
Size:Cable length:150mm/Total length:175mm
Connector:SMA
Feature:
-A hexagonal shape for enhanced durability and a right-angle design for convenient fixation.
-Utilizes ultrasonic welding technology to ensure a lightweight yet secure antenna attachment.
-Achieves higher consistency in antenna gain, thereby improving device performance and stability.
Package List:
1 x 4.9G FPV Antenna
Sale!
iFlight Albatross V2 SMA 4.9-5.2Ghz 3dBi Gain Omnidirectional FPV Antenna SMA Male RHCP 15cm For RC Racer Drone
$17.20
+ Free ShippingAvailability: 2954 in stock
Weight | 0.2 kg |
---|---|
Dimensions | 10 × 10 × 5 cm |
Hign-concerned Chemical | None |
Is Electric | No Battery |
Quantity | 1 pcs |
Wheelbase | Bottom Plate |
Is it battery/power supply | N |
Is it charger/adapter | N |
Is Batteries Included | No |
Technical parameters | value 2 |
Model Number | iFlight Albatross V2 SMA 4.9Ghz Antenna |
For Vehicle Type | Airplanes |
Tool Supplies | Battery |
Four-wheel Drive Attributes | Assemblage |
Remote Control Peripherals/Devices | Remote Controller |
Upgrade Parts/Accessories | Frame |
RC Parts & Accs | Antennas |
Material | Metal |
Origin | Mainland China |
Recommend Age | 14+y |
Use | Vehicles & Remote Control Toys |
Certification | CE |
