Description:
Brand Name:FlySky
FS-i6X Specifications:
Item: FS-i6X RC Transmitter
Channel: 6-10 (Default 6)
Mode: mode 2 is left throttle hand (throttle stick on the left side)
Model Type: Fixed-Wing/Glider/Helicopter
RF Range: 2.408-2.475GHz
RF Power: < 20dBm
RF Channel: 135
Bandwidth: 500KHz
2.4GHz System: AFHDS 2A / AFDHS
Modulation Type: GFSK
Stick Resolution 4096
Low Voltage Warning: < 4.2V
DSC port: PS/2 Port PPM
Chargeable: No
Antenna Length: 26mm (Dual Antenna)
Weight: 392g
Power: 6V DC 1.5AA*4
Display: STNTransflective Display, LCD 128×64 Lattice, VA 73x39mm, LCD with white backlight
Size: 174x89x190mm
On-line Update: Yes
Color: Black
Certificate: CE0678, FCC ID: N4ZFLYSKYI6X
Mode: Mode 1(right hand throttle), mode 2(left hand throttle)
Note:
Only i6x means the package comes without receiver, only i6x
transmitter. This transmitter comes wtih 6 channels, it need to modify
by yourself if you wanna it be 10 channel.Battery not included
Only i6x means the package comes without receiver, only i6x
transmitter. This transmitter comes wtih 6 channels, it need to modify
by yourself if you wanna it be 10 channel.Battery not included
Features:
The
AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation)
developed and petented by FLYSKY is specialy developed for all radio
control models. Offering superior protection against interference while
maintaining lower power consumption and high reliable receiver
senstivity, FLYSKY’s AFHDS technology is considered to be one of the
leaders in the RC market today.
AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation)
developed and petented by FLYSKY is specialy developed for all radio
control models. Offering superior protection against interference while
maintaining lower power consumption and high reliable receiver
senstivity, FLYSKY’s AFHDS technology is considered to be one of the
leaders in the RC market today.
Bidirectional Communication
Capable
of sending and receiving data, each transmitter is capable of receiving
data from temperature, altitude and many other types of sensors, servo
calibration and i-BUS Support.
of sending and receiving data, each transmitter is capable of receiving
data from temperature, altitude and many other types of sensors, servo
calibration and i-BUS Support.
Multi-channel Hopping Frequency
This
system bandwidth ranges from 2.408GHz to 2.475GHz. This is divided in
135 channels. Each transmitter hops between 16 channels (32 for Japanese
and Korean version) in order to reduce interference from other
transmitters.
system bandwidth ranges from 2.408GHz to 2.475GHz. This is divided in
135 channels. Each transmitter hops between 16 channels (32 for Japanese
and Korean version) in order to reduce interference from other
transmitters.
Omni-directional Gain Antenna
The
high efficiency Omni-directional high gain antenna cuts down on
interference, while using less power and maintaining a strong reliable
connection.
high efficiency Omni-directional high gain antenna cuts down on
interference, while using less power and maintaining a strong reliable
connection.
Unique ID Recgnition System
Each
transmitter and receiver has it’s own unique ID. Once the transmitter
and receiver have been paired, they will only communicate with each
other, preventing other systems accidentally connecting to or
interfering with the systems operation.
transmitter and receiver has it’s own unique ID. Once the transmitter
and receiver have been paired, they will only communicate with each
other, preventing other systems accidentally connecting to or
interfering with the systems operation.
Low Power Consumption
The
system is built using highly sensitive low power consumption
components, maintaining high receiver sensitivity, while consuming as
little as one tenth the power of a standard FM system, dramatically
extending battery life.
system is built using highly sensitive low power consumption
components, maintaining high receiver sensitivity, while consuming as
little as one tenth the power of a standard FM system, dramatically
extending battery life.
FS-IA6B Specifications:
Item Name: IA6B
Channel: 6
Model type: fixed wing/helicopter/glider
RF receiver sensitivity: -105dBm
Modulation: GFSK
System type: AFHDS2A/AFHDS
Channel resolution: 1024 steps
Bind port: yes
Power port: yes( VCC)
Power: 4V -6.5V DC
Weight: 14.9g
Antenna lenght: 26mm
Size: 47.4*262.2*15 mm
Certificate: CE ,FCC
